The Power of Sonar: A High-Tech Way to Map Your Drains

Whether you’re building a conservatory, extending your home or constructing an out-building, you will need to know the exact depth and location of all drains in the construction area.

Sonar technology and sonar surveys may seem from the realm of 007, but it’s the most reliable way to perform this drain mapping.

CCTV drain surveys are commonly conducted for drain mapping purposes, and these give us plenty of useful visual information – all except the precise location and depth of the pipe.

That’s where the power of sonar comes in, and this technology can be used in partnership with cameras to give a truly accurate, precise result.

But how does this technology work, and when is it useful?

How Does Sonar Drain Tracing Work?

So what is sonar and how does it work? Sometimes called ‘sonding’, the process of sonar drain tracing works by putting a sonde (a self-contained sonar transmitter) onto a crawler device – this could be a flexible rod or a camera, for example. This sonde is then fed deep into the drain.

At each position that the engineer wants to take a reading from, the transmitter will send a sonar pulse outwards in a circular configuration. A trained technician will be waiting above ground with a receiver device to take the reading – they will be able to adjust and prepare the receiver to take accurate measurements depending on the sonar frequency emitted.

Measuring these pulses allows the experts to not only pinpoint the location of a drain or a drain issue, but also determine how deep down the drain is by measuring the distance between the sonde underground and receiver device above ground.

The Benefits of Sonar Technology

  • Relays the accurate depth and location of a drain, allowing for a drainage plan to be drawn up – making it an essential part of a project’s planning process.
  • Avoids costly accidents – for example, if a drain is hit and damaged, this could result in delays and expense to rectify it.
  • Can identify collapsed drains or drain blockages, allowing for quick diagnosis and correction.
  • Gives up-to-date readings that can be trusted above old drain maps available from your local authority, which may be out of date.
  • Allows for clarity in more complex drainage layouts.
  • Can be mounted on a camera, providing a double advantage of a visual inspection and tracing.

When Might You Need Sonar Drain Tracing?

Discovering the precise location and depth of a drain with a sonde drainage survey is useful in a number of situations:

  • If you’re extending your home or making alterations to a property, you will need to ensure you’re not too close to public sewers. If you are, you’ll require permission from the local authority.
  • If you need to dig up a drain, but are unsure of exactly where it is. Without accurate drain tracing, it can involve time-consuming guesswork to locate the drain.
  • If you suspect a collapsed drain or a blockage, a sonde can work in partnership with a CCTV camera for a sonde drainage survey to assess exactly where the problem is located, what depth it’s at, the severity of the issue, and any potential obstacles to a resolution.

Express Drainage Solutions provided drainage solutions for 20,000+ residents & businesses of London and the surrounding areas in the past 12 months alone. Our wide range of services includes: drain unblocking, rodent control, drain mapping/surveying, drain installation & repair, septic tank/cesspit installation, repair & emptying, flood response & much more.

Do you want to harness the power of sonar for your project? Here at Express Drainage Solutions, we use top caliber sonar drain tracing equipment:only state-of-the-art sonding transmitters and CCTV cameras for a variety of projects – allowing us to accurately map drains, or even to diagnose drainage problems.

Our trained engineers can assist homes and businesses throughout London and beyond – get in touch to discover more.
